Electric Chain Hoist ER2 Series

Capacity : 125kg to 20t

Power supply : 380V, 50Hz., 3Ph.

Speed :

Single Speed
Dual Speed (Inverter)

KITO ER2 Series are key players in the KITO Electric Chain Hoists, featuring superior performance as a high quality, high performance crane with state-of-the-art specifications. Seeking improved ease of use and work efficiency, an inverter has been provided as standard in a dual speed hoist and trolley. The dual speed inverter delivers smoother movement than ever, reducing load swing.

    • Smooth & Ergonomic Operation
    • Reliable Safety
    • Enhanced Durability
    • Easier Maintenance
    • Environmentally Friendly
รอกโซ่ไฟฟ้า Kito ER2

No hazardous substances as an environmental measure, several environmentally hazardous substances specified by KITO, including 6 European RoHS directive substances, are not used.

Further, an energy-savings can be made due to reduction in rated current draw compared to the previous ER.

The utilization of the inverter, 4-pole motor as well as the electromagnetic brake, reduces the noise during operation and braking

ER2 360° View

Kito Body ER2

Compact Body Light weight

The compact aluminum die-cast body has exceptional rigidity as well as, high dust-protection and water-protection. It has a simple structure with a small number of parts. Fine-tuned profile of load chain link benefits loss of the hoist body weight compared to the previous ER.



ER2 Dual Speed-Inverter Inverter smooth transitional speed”

Reliable Safety

Safety is the most important task for lifting equipment

Maintaining safety is the most important task for lifting equipment, and is essential for stable operation. To ensure safety, KITO utilizes a double safety mechanism consisting of

  1. The friction clutch is an emergency overload protection device that idles the motor when subjected to an excessive load over the rated capacity. Friction clutch performance is not easily compromised with changes in the surrounding temperature. In the case of irregular
    loading, this operates in advance to prevent the hoist body or load chain from being damaged.
  2. The Limit Switch is a safety feature designed to cut off power in case of an overload during both upward and downward movements. This action helps protect the hoist and chain from damage by stopping the motor.

To prevent the motor from burning out due to excessive usage, a standard thermal protector is installed in the motor.

Connected in series to a motor circuit, a current-driven electromagnetic brake does not release unless the motor is energized. This concurrent drive increases safety of the circuit compared to separate circuits for the motor and the brake.

The emergency stop, provided as standard, allows the motor power
to be disconnected in an emergency without cutting off the main power supply.

ปุ่ม emergency ER2
ลิมิตสวิชท์ ER2
โซ่ ER2

Enhanced Durability

Load chain (super strength)

KITO’s world class original supper-strength nickel-plated load chain certified by German Institute, uses unique technology to greatly increase resistance to fatigue and wear.

Unique motor frame fins & fan cover

A unique fan-cooled motor with motor frame fins and a fan cover have been configured into a purpose built design. This design produces a much quieter motor unit as well as enhanced fan cooling capabilities.

มอเตอร์ ER2
Cover พัดลม ER2

Easier Maintenance



CH (counter hour) meter

As a standard feature, the hoist’s total on-time and the number of lowering starts are shown on the LCD of the CH meter. This enables the user to carry out maintenance based upon the frequency of use. By maintaining a history of the CH meter data, the inspection periods and replacement periods for gear oil, contactors, brakes and load chains can be efficiently controlled, allowing the equipment to be used with confidence.



Convenient Part Replacement

Our equipment features a design where components and electrical parts are housed within the body cover, making maintenance and part replacement easy.

Trolley

Kito Trolley ไฟฟ้า 2.8 ตัน

Motorized Trolley MR2

  • Simple gear box construction
  • Improved balance due to a lighter weight geared motor
  • Speed variations

Apply to ER2 (125kg-20t)

รุ่น ER2M

รอกโซ่ไฟฟ้า Kito ER2M 1 ตัน
Kito Trolley มือผลัก 1 ตัน

Plain Trolley TSP

  • light load manual applications
  • Lugs provide protection from striking damage against rail stoppers, and from falling off the rail.
  • Wheel flanges also prevent derailment.

Apply to ER2 (125kg-5t)

รุ่น ER2SP

รอกโซ่ไฟฟ้า Kito ER2SP 1 ตัน

Geared Trolley TSG

  • precise positioning and traversing by using hand chain
  • Lugs provide protection from striking damage against rail stoppers, and from falling off the rail.
  • Wheel flanges also prevent derailment.

Apply to ER2 (125kg-20t)

รุ่น ER2SG

รอกโซ่ไฟฟ้า Kito ER2SG 1 ตัน
