Wire Rope Hoist RY Series

Capacity : 3.2t / 5t

Power supply : 380V, 50Hz., 3Ph.

Speed : Dual Speed (Inverter)

KITO’s manufacturing begins with a focus on customers’ “safety”. How to enhance “safety” is considered in every step of KITO’s technical innovation. This design philosophy forms the basis of KITO’s RY Series Wire Rope Hoist. RY Series Wire Rope Hoist, inspired by KITO’s strict standard for safety, will provide exceptional values for users all over the world. Smooth & Ergonomic Operation

- Reliable Safety
- Enhanced Durability
- Easier Maintenance
- Smooth & Ergonomic Operation
- Environmentally Friendly

Compact Body Light weight

A simple, modern and functional design accommodates wide variety of applications and demands.

“RY Dual Speed-Inverter provides a gentle and smooth operation.”

Reliable Safety

Safety is the most important task for lifting equipment

Lower control voltage for the pendant

DC24V for improved safety

Equipped with the inverter as standard

(lifting/lowering and traversing)
Smooth operation with the anti-jogging feature for lifting/lowering. The soft start/stop minimizes the swing of a load.

Electronic overload limiter

Detects overload instantaneously and shuts off the circuit for lifting.

Electronic thermal motor protection

Detects overheat and stops the operation to protect the motor.

Upper/lower limit switch

Upper/lower limits are adjustable to set the range of operation.

Pull rotor type motor brake

Durable brake rated for more than 1 million cycles.

high-strength wire rope

Equipped with high-strength wire rope to reduce weight and size of the unit (5t models or higher).

Serviceability

CH meter (inverter built-in function)

The number of starts and operating hours are displayed on the LED, enabling users to perform maintenance and inspection in accordance with the frequency of use.
